PT-A: Ultrasonic Scaler and Aeropolisher - WOODPECKER
Brand:WOODPECKER
Reference:DTX-28-PTA
Manufacturer Ref.:28-PTA
When you buy this air polisher, we'll give you a free transport cart (ref: DTX-28-CART2).
Plus, enter the code WOOD8 and get an 8% discount on this product.
Complete solution for prophylaxis:
- Automatic selection according to the handpiece being lifted.
- “Painless” ultrasound technology for painless treatments.
- With water heater to eliminate pain and sensitivity generated by cold water during treatment.
- Large liquid- and splash-proof touch screen that perceives touch with gloves or through protective film.
- The handpiece is activated through the multifunction pedal, allowing the "boost" mode to be activated to temporarily increase power, as well as dry cleaning.
Fastest delivery between Thursday, October 29 - Friday, October 30 — order within the next 17 h and 0 min.
Best sellers ranking:
- #3 in Combined Ultrasonic and Aeropulse
- #4778 in all Dentaltix
You have 15 days to return it.Frequently bought together
PT-A: Ultrasonic Scaler and Aeropolisher
€5,542.86 €3,880.00
Cart for Ultrasonic Scaler + AP-B and AP-A Aeropolisher
€700.00 €490.00
Fast PT-S1: Bicarbonate powder (300 gr)
€21.36 €14.95
Gentle PT-S3: Glycine for Air Polisher (Lemon Flavor)
€21.14 €14.80
Description
Woodpecker · Ref. DTX-28-PTA
Woodpecker PT-A: Ultrasonic Scaler and Dental Air Polisher
A complete solution for flawless prophylaxis. Two integrated systems in a single tabletop unit: a piezoelectric ultrasonic scaler with "Painless" technology and a 2-in-1 air polisher for supragingival and subgingival use. Backed by 35 national patents, 5 of them invention patents.
Smart control
7" touchscreen for the ultrasonic scaler: operable with gloves
The large 7" LCD touchscreen responds to touch even through gloves or protective film. It offers 12 flow adjustment levels and 12 power levels, with three working programmes: Cleaning (G), Periodontics (P) and Endodontics (E).
Automatic mode recognition is one of its key differentiators: the unit detects which handpiece has been lifted from the holder and switches the working mode instantly, with no manual input.
Ultrasonic scaler
"Painless" technology: piezoelectric ultrasonics for pain-free treatment
The scaler's elliptical vibration disperses the impact force between the tip and the tooth, allowing work at 0° to the tooth surface and achieving 360° cleaning. The result is effective scaling that significantly reduces patient discomfort.
The YZ-2L handpiece is detachable, autoclavable and compatible with EMS-type tips. The built-in water heater eliminates the sensitivity caused by cold water. Water can be supplied from an independent reservoir or the mains, and clinical solutions such as chlorhexidine or hypochlorite can be used.
14 tips included
Titanium scaler tips: prophylaxis, periodontics, endodontics and implants
The PT-A includes 14 titanium alloy tips designed to cover every clinical need: prophylaxis, periodontics, endodontics and implant maintenance.
Their HRC30 hardness is lower than that of tooth enamel (conventional stainless steel reaches HRC50), ensuring the tips do not damage tooth surfaces. Working at 0° to the tooth surface allows effective polishing with no risk to the tissues.
2-in-1 air polisher
Supragingival and subgingival dental air polisher in a single unit
The AP-1 (supragingival) handpiece delivers a ø0.7mm powder jet surrounded by a ring of water that protects the soft tissues, and is compatible with 40–65μm sodium bicarbonate and glycine powders. Its anti-clogging, aerodynamic design prevents pressure loss and blockages.
The AP-2 (subgingival) handpiece, made of flexible medical-grade polymer with 360° rotation, reaches hard-to-access areas, delivering three powder jets and one water jet. Compatible with 25μm glycine.
Clinical effectiveness
Removal of plaque, staining and biofilm: superior clinical results
The air polisher is particularly effective in hard-to-reach areas: occlusal and interproximal surfaces, orthodontic brackets and peri-implant areas. After ultrasonic scaling, air polishing leaves a smoother tooth surface, reducing future plaque and stain build-up.
Subgingival treatment effectively controls inflammation around natural teeth and in peri-implantitis, reducing probing depth more precisely than traditional scaling. It does not scratch the tooth surface or damage the soft tissues.
Hands-free control
Multifunction foot pedal for the ultrasonic scaler with 4 working modes
The multifunction foot pedal keeps the clinician's hands free during treatment. It activates Boost mode to increase power temporarily and switches between working modes without touching the screen.
Dual water reservoir
600 ml and 1,400 ml water reservoirs with built-in heater
The PT-A includes two interchangeable water reservoirs made of anti-corrosion material: a 600 ml one for short sessions and a 1,400 ml one for long sessions or several patients.
Both can be used with special clinical solutions such as chlorhexidine, hydrogen peroxide or sodium hypochlorite. The built-in water heater markedly improves patient comfort. A mains water supply can also be connected.
Universal compatibility
Scaler compatible with EMS-type tips: 360° LED and autoclavable
The YZ-2L handpiece uses the standard thread system compatible with EMS-type tips, one of the most widespread connections on the dental market, giving access to a wide range of tips for different clinical indications.
It features 360° LED lighting, separates into three parts for thorough cleaning and is autoclavable. The warranty is 24 months for the unit and 12 months for the handpieces.
Demonstration video
Woodpecker PT-A in clinical use
Take a detailed look at each part of the unit and how it works in clinical practice.
Installation
How to install the Woodpecker PT-A step by step
A complete installation guide for setting up the PT-A ultrasonic scaler and air polisher in the clinic.
Woodpecker PT-A Technical Specifications
Full technical data for the PT-A ultrasonic scaler and air polisher.
Main unit
Ultrasonic scaler
Air polisher
Water reservoirs
Woodpecker PT-A box contents
Ultrasonic scaler
- 2 YZ-2L handpieces (detachable and autoclavable)
- 14 titanium tips
- 2 TW-5L torque wrenches
- 2 fixed wrenches
- 1 sterilisation box for handpiece and accessories
- 1 filter wrench
Air polisher
- 2 transparent powder chambers (65μm and 25μm)
- AP-1 supragingival handpiece
- AP-2 subgingival handpiece
- 1 bottle of Bicarbonate Fast PT-S1
- 1 bottle of Glycine Gentle Mini PT-S3
- 10 subgingival nozzles
- Subgingival nozzle wrench
- 2 sterilisation boxes for the air polisher
General
- 2 water reservoirs (600 ml and 1,400 ml)
- Multifunction foot pedal
- 1 air filter and 1 water filter
- O-ring set
- 2 LEDs for handpieces
- Installation accessories (connectors and tubing)
- Metal carrying case
